Контактор силовой для KASTEL (00005140)
Характеристики:
омоническая нагрузка: 20 А
питание: 230 В
главные контакты: 3NO
вспомогательные контакты: 1NO
присоединение: винтовое соединение
мощность мотора (AC3/400V): 8,5A/5,5 кВт
тип FANAL: DSL7 10
тип ISKRA: K07M 10
Подходит для моделей:
ADLER:
CF235, CF35, CF35-1, CF35-1DP, CF35DP, CF40-1DL, CF40-1DLDP, CF40DL, CF40DLDP, CF50, CF50A, CF50A400, CF50ADP, CF50ADP400, CF50DP, CF50DPPD, COMPACT-EXTRACTIBLE, DL240, DL240-1, DL240-1DP, DL240DP, DS101, DS103, DS11, DS13, DS201, DS203, DS21, DS23, DS412, DS412PD, DSF101, DSF103, DSF11, DSF13
ANGELO PO:
BX101E, BX101E VERS 12-2013, BX101G, BX101G VERS 12-2013, BX122E, BX122E MY2016, BX122E VERS 12-2013, BX122G, BX122G MY2016, BX122G VERS 12-2013, BX61E, BX61E MY2016, BX61E VERS 12-2013, BX61G, BX61G MY2016, BX61G VERS 12-2013, BX82E, BX82E MY2016, BX82E VERS 12-2013, BX82G, BX82G MY2016, BX82G VERS 12-2013, FM1011E1, FM1011E1 VERS 2006, FM1011E2, FM1011E2 VERS 2006, FM1011E3, FM1011E3 VERS 2006, FM1011G1, FM1011G1 VERS 2006, FM1011G2, FM1011G2 VERS 2006, FM1011G3, FM1011G3 VERS 2006, FM1221E1, FM1221E1 VERS 2006, FM1221E2, FM1221E2 VERS 2006, FM1221E3, FM1221E3 VERS 2006, FM1221G1, FM1221G1 VERS 2006, FM1221G2, FM1221G2 VERS 2006, FM1221G3, FM1221G3 VERS 2006, FM2011E2 VERS 2006, FM2011E3 VERS 2006, FM2011G2 VERS 2006, FM2011G3 VERS 2006, FM2021E1, FM2021E2, FM2021E2 VERS 2006, FM2021E3, FM2021E3 VERS 2006, FM2021G1, FM2021G2, FM2021G2 VERS 2006, FM2021G3, FM2021G3 VERS 2006, FM611E1, FM611E1 VERS 2006, FM611E2, FM611E2 VERS 2006, FM611E3, FM611E3 VERS 2006, FM611G1, FM611G1 VERS 2006, FM611G2, FM611G2 VERS 2006, FM611G3, FM611G3 VERS 2006, FM721E1, FM721E1 VERS 2006, FM721E2, FM721E2 VERS 2006, FM721E3, FM721E3 VERS 2006, FM721G1, FM721G1 VERS 2006, FM721G2, FM721G2 VERS 2006, FM721G3, FM721G3 VERS 2006, FX101E1, FX101E1R, FX101E2, FX101E2 VERS 03-2014, FX101E2C, FX101E2C VERS 03-2014, FX101E2R, FX101E2R VERS 03-2014, FX101G1, FX101G1R, FX101G2, FX101G2 VERS 03-2014, FX101G2C, FX101G2C VERS 03-2014, FX101G2R, FX101G2R VERS 03-2014, FX10E2CR, FX10E2CR VERS 03-2014, FX10G2CR, FX10G2CR VERS 03-2014, FX122E1, FX122E2, FX122E2C, FX122E2T, FX122E2T VERS 03-2014, FX122G1, FX122G2, FX122G2C, FX122G2T, FX122G2T VERS 03-2014, FX201E2, FX201E2 VERS 03-2014, FX201E2P, FX201E2P VERS 03-2014, FX201G2, FX201G2 VERS 03-2014, FX201G2P, FX201G2P VERS 03-2014, FX202E2, FX202E2 VERS 03-2014, FX202G2, FX202G2 VERS 03-2014, FX61E1, FX61E1R, FX61E2, FX61E2 VERS 03-2014, FX61E2C, FX61E2C VERS 03-2014, FX61E2CR, FX61E2CR VERS 03-2014, FX61E2R, FX61E2R VERS 03-2014, FX61E3, FX61E3 MY2016, FX61E3 VERS 02-2014, FX61E3C, FX61E3C MY2016, FX61E3C VERS 02-2014, FX61E3CR, FX61E3CR VERS 02-2014, FX61E3P MY2016, FX61E3R, FX61E3R MY2016, FX61E3R VERS 02-2014, FX61G1, FX61G1R, FX61G2, FX61G2 VERS 03-2014, FX61G2C, FX61G2C VERS 03-2014, FX61G2CR, FX61G2CR VERS 03-2014, FX61G2R, FX61G2R VERS 03-2014, FX82E1, FX82E2, FX82E2C, FX82E2T, FX82E2T VERS 03-2014, FX82G1, FX82G2, FX82G2C, FX82G2T, FX82G2T VERS 03-2014, 06WFT1EV, 06WFT2EV, 06WFT3EV, 06WFT4EV, 06WFT6EV, 06WFT7EV, 08WFT1EV, 08WFT2EV, 08WFT3EV, 08WFT4EV, 08WFT6EV, 08WFT7EV, 091FT1E, 091FT2E, 091FT4E, 091FT5E, 091FT7E, 0G1FT2E, 0G1FT4E, 0G1FT5E, 0G1FT7E, 191FT1E, 191FT2E, 191FT3E, 191FT4E, 191FT6E, 191FT7E, 1G1FT2E, 1G1FT4E, 1G1FT5E, 1G1FT6E, 1G1FT7E
ARISTARCO:
AE1000, AE1200, AE45.30, AE50.32, AE50.35, AH1000, AH1000EASY, AH1100, AH1100DGT, AH1200, AH1200DGT, AL40.28, AL40.28E, AL45.32, AL45.32E, AL50.34, AL50.34E, AL50.34EM, AL50.40, AL50.40E, AL50.40EM, ALISEO40.28E, ALISEO45.32E, AP1000, AP1200, AP45.30, AP45.30DA, AP50.32, AP50.32DA, AP50.35, AP50.35DA, AP55.40, AP55.40DA, AS50.35, AS50.35DA, AS50.35DGT, AS50.35DGT-DA, AS50.40, AS50.40DA, AS50.40DGT, AS50.40DGT-DA, AU-P55.40, AU-S55.40, AU-S55.40DGT, AU125-80, AW4028, AW45.32, EMA75, EMA80, AE 45.30, AE 50.32, AE 50.35, AE 50.35 H, AP 45.30, AP 45.30 D.A., AP 50.32, AP 50.32 D.A., AP 50.35, AP 50.35 D.A., AP 55.40, AP 55.40 D.A., EURO 500, GL 7.40 E.M., LP 125-80, LP 55-65, AE 1000, AE 1200, AH 1000, AH 1000 EASY, AH 1040 BTI, AH 1040E, AH 1040E-D.A., AH 1040E-ES, AH 1040E-PRS, AH 1100, AH 1100 DGT, AH 1200, AH 1200 DGT, AH 1240 BTI, AH 1240E, AH 1240E-D.A., AH 1240E-ES, AH 1240E-PRS, AH 800, AH 800 E, AH 800 E-D.A., AH 800 E-ES, AH 800 E-PRS, AH 800M, AP 1000, AP 1200, AL 40.28, AL 40.28 E, AL 45.32, AL 45.32 E, AL 50.34, AL 50.34 E, AL 50.34 EM, AL 50.40, AL 50.40 E, AL 50.40 EM, ALISEO 40.28 E, ALISEO 45.32 E, AS 50.35, AS 50.35 D.A., AS 50.35 DGT, AS 50.35DGT-DA, AS 50.35E, AS 50.35E-DA, AS 55.40, AS 55.40 D.A., AS 55.40 DGT, AS 55.40DGT-DA, AS 55.40E, AS 55.40E-DA, AU 125-80, AU 125-80E ES, AU 125-80E PRS, AU 55-65, AU 55-65E ES, AU 55-65E PRS, AU 55-80, AU 55-80E ES, AU 55-80E PRS, AU 65-65, AU 65-65E ES, AU 65-65E PRS, AU-P 55.40, AU-S 55.40, AU-S 55.40 DGT, AU-S 55.40E, AW 40.28, AW 45.32
COMENDA:
C1000E, C1000ERCD, C1000ERCD CRC2, C1001M, C1300E, C1300ERCD, C1301M, CL70, LC1200, LC1200MRCD, LC412, LC700, LC700E2, LC700MRCD, LC900, LC900E2, LC900MCRC, LC900MRCD, RC412C, XLC, XLC CRC2, XLC MPS, GE50RCD
DIHR:
5+5M, 5M, 6+6M, 6+6T, 6M, 6T, 8+8T, 8T, DS45, DS50, DS50-TOUCHE, DS50T, DUPLA50, DW020H, ELECTRON1000, ELECTRON400, ELECTRON400CLEANWATER, ELECTRON500, ELECTRON500CLEANWATER, ELECTRON500PLUS, ELECTRON600, G600, G600S, GASTRO-11-S, GASTRO-11-S-ISOLATA, GASTRO-11S, GASTRO-1200-S, GASTRO-1200-S-ISOLATA, GASTRO-450, GASTRO-500, GASTRO-750, GASTRO-900, GASTRO11S, GASTRO1200, GASTRO12S, GASTRO400S, GASTRO450, GASTRO500PLUS, GASTRO500S, GASTRO750PLUS, GASTRO750S, GRANUL1000, 102U (GS40), 106EK (PREMIUM40), 108EU (OPTIMA500 CUTLERY), 10U (GS40), 111EN (HT12E), 111EU (HT12E), 115U (OPTIMAHR), 121EN (DS50), 122EU (ELECTRON600), 123EU (ELECTRON1000 PLUS), 124EU (ELECTRON500), 124PU (ELECTRON500), 125EU (ELECTRON400), 19ER (LP3 ELETTRONICA), 20ELK (ELECTRON1000), 20U (GS100), 295U (GASTRO500 PLUS), 297R (GASTRO750 PLUS), 297U (GASTRO750 PLUS), 29ELK (ELECTRON500), 29P (TEKNO6), 29R (TEKNO6), 29S (GASTRO500), 29S (GASTRO750S), 31R (GS45), 31U (GS45), 32ELK (ELECTRON400), 32ELKC (ELECTRON400 ACQUA PULITA), 32P (TEKNO4), 32R (TEKNO4), 38R (G600), 38U (G600), 66R (GS85), 66U (GS85), 6R (LINEAR), 6U (LINEAR), 74R (GS40), 74U (GS40), 78R (DS50), 78U (DS50), 78UT (DS50 TOUCHE RL09), 7R (GASTRO450), 7U (GASTRO450), 81E (LP3S PLUS), 81E (LP3STR PLUS), 83ELK (ELECTRON600), 9R (GS50), 9U (GS50), ELECTRON500 CLEAN, GASTRO750, GASTRO900, H63E (H600 ELETTRONICA)
ELOMA:
EBM3E-MCDONALDS, EBM5, EDC6-11, ELH101, ELH5-3-MCDONALDS, ELH51, ELH53, ELH61, HUD511, MD523, MD611, MMC1011, MMC611, MMD1011, MMD611
FIAMMA:
F-532, FCF10, FCF10+10, FCF10+10-TR, FCF10-TR, FCF15+15, FCF15-TR, FCF6, FCF6+6, FF-10, FF-10+10, FF-10+10-TR, FF-10-TR, FF10, FF10+10, FF10+10TR, FF10+10TR-NV, FF10TR, FF10TR-NV, FF6, FF6+6, PPEF-800, PPEF-800-CRD, PPEF-M-800, PPEF-M-800-CRD
Альтернативные коды:
20538 - ADLER
15086 - ALBA
15086/F - ALBA
15086/F - ALPENINOX
00005140 - ARISTARCO
5140 - ARISTARCO
DH..38 - ASCASO
DH.633 - ASCASO
FRG172 - ASCASO
DH.633 - BOBECK
E15086 - BOBECK
23594 - BREMA
FRG172 - CF CENEDESE
FRG172 - COLGED
FRG172 - COMENDA
B-00-0004 - DALLA CORTE
15086 - DESCO
DH.633 - DESCO
019033 - DEXION
19033 - DEXION
0015086 - DIHR
15086 - DIHR
15086/F - DIHR
DH.633 - DIHR
DW15086 - DIHR
086215 - ELECTROLUX
86215 - ELECTROLUX
DW15086 - ELECTROLUX
FRG172 - ELETTROBAR
FRG172 - ELFRAMO
324001 - ELOMA
EL0324001 - ELOMA
ELE324001 - ELOMA
3700080 - EMAINOX
23594 - EMMEPI
23594 - EVERLASTING
PR70015 - FABA
12030879 - FAGOR
BR00023594 - FAGOR
FRG172 - FB FABA
4.0.089.0003 - FIAMMA RST
380083 - GEV
380213 - GEV
380083 - HOONVED
380083 - KOMEL
0015086 - KROMO
15086 - KROMO
15086/F - KROMO
380213 - KROMO
DW15086 - KROMO
11BF901220230 - LOVATO
11BF9012305060 - LOVATO
11BG09T4A230 - LOVATO
BF0901230 - LOVATO
BF0901A230 - LOVATO
N23594 - LUXIA
500035100 - MACH
80001 - MACH
80001857 - MACH
80001LT029 - MACH
BF0901A230 - MARELS
019033 - MBM
BF0901A230 - MBM
BF0901A230 - MEIKO
15086 - METOS
15086/F - METOS
380213 - METOS
DW15086 - METOS
BF0901A230 - MODULAR
EWG005 - NORTH
N23594 - NTF
15086 - OLIS
5403500 - PIZZA GROUP
BF0901A230 - REPAGAS
380213 - RHIMA
50910008 - RHIMA
50910041 - RHIMA
00002871 - RM GASTRO
8900310 - ROKA
A05008 - ROLLER GRILL
BF0901A230 - ROLLER GRILL
RX94807062 - ROSINOX
380213 - SAGI
BF0901A230 - SAGI
BF0901A230 - SPAZIALE
073050 - STAR10
RX94807062 - ZANUSSI
